Basic Electric Circuit
- Availibility: In Stock
Components Required:
- Power Supply (e.g., 9V battery or DC power source)
- Resistors (Various values for demonstration, e.g., 1kΩ, 10kΩ)
- Capacitor (e.g., 100µF for demonstration)
- Switch (Single-pole switch for controlling circuit flow)
- LED (Light Emitting Diode for visual indication)
- Connecting Wires (Insulated copper wires for connections)
- Breadboard (For assembling the circuit without soldering)
- Multimeter (For measuring voltage, current, and resistance)
- Baseboard (Optional, for mounting the breadboard and components)
Qty
Your Transaction is Secure
We work hard to Protect your Security and Privacy. Our Payment Security System Encrypts your information during transmission.
Share this Link
Description
Project Description: This project involves building a basic electric circuit on a breadboard. The circuit includes a power supply, a switch, resistors, and an LED. The goal is to demonstrate how electrical components interact in a simple circuit and to observe how changing component values affects circuit behavior.
In this project, students will connect the components to form a series circuit. When the switch is closed, current flows through the resistors and LED, causing the LED to light up. By measuring voltage across different components and current through the circuit, students can explore basic electrical concepts such as Ohm's Law and the relationship between voltage, current, and resistance.
The project serves as an introduction to more complex circuits and provides a foundation for understanding electrical principles and component functions.
Applications:
- Understanding basic electrical components and their functions
- Demonstrating principles of Ohm's Law and Kirchhoff's Laws
- Practical experience in building and testing simple electrical circuits
- Educational tool for learning about current flow, resistance, and voltage
